Product Description
01 Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency.
02 Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation.
03 Gearbox using 4 × 3 (1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency.
04 Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements.
05 Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy.
06 Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good.
07 Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned.
08 Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio.
09 New streamlined appearance, generous, modern, fashion.
10 Control levers can be mounted at side as optional, more convenient and comfortable.
Product Parameters
| Rated Power (HP) | 73.5kW/100HP |
| Type | Wheel Tractor |
| Place of Origin | China |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 1 Year |
| Core Components | Motor, Pump, Pressure vessel, Gearbox, Engine, Gear, PLC, Bearing |
| Engine Brand | Quanchai |
| Weight | 3250 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | Louton |
| Key Selling Points | High Productivity, High Safety Level, Long Service Life |
| Product name | Mini Farm Tractor |
| Model | LTB1004 |
| Overall Dimension | 4230*1750*2820mm |
| Rated tractor force | 23.8875kN |
| Wheel tread(front/rear) | 1420/1352 |
| Wheelbase | 2070mm |
| Min. ground clearance | 400mm |
| Number of cylinders | 4 |
| Engine Rated speed | 2400r/min |
| Engine Rated power | 73.5kW |
FAQ
Q1：Are you a Manufacturer or Trader?
A1:We are a professional manufacturer, we have our own R&D team and sales team, we provide one-stop service.
Q2: What is your terms of payment?
A2: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3: What is your terms of delivery?
A3: EXW, FOB, CFR, CIF.
Q4: What is your delivery time?
A4:Usually, we make merchandise inventory, if we have the products in stock, the delivery time is 5-10 days after receiving the deposit.If we don't have the products in stock, we will arrange the production right now, the delivery time will be 15-30 days, it depend on the order quantity.
Q5: Do you provide OEM/ODM service?
A5:Yes, offer me necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
Q6: How to install the equipment after purchasing ?
AA6: We will provide professional installation video to illustrate.Also provide manual.
Q7: Do you offer a guarantee or warranty?
A7: 1 year warranty. 24 hours online service, If the spare parts are damaged, we will send within 24 hours.
